Your card held 1,093 JPEGs. Every one since June 23 was shot on the light-bulb white balance, which is why the last 286 came out blue. One button fixes that. Here's that fix, four more, and how to run this camera after that.
About fifteen minutes with the camera in your hands. Tick each one as you go; this page remembers on this device.
0 of 5 done on the camera
Press WB on the top plate, turn a dial to AWB, half-press the shutter. There's no white balance item in the menus; it lives on that button.
Why: Incandescent tells the camera the light is orange tungsten, so it adds blue to cancel it. Outdoors there's no orange to cancel, so everything just goes blue. Auto reads the real light on every frame. (AWBc strips warmth from indoor light, AWBw keeps it. Plain AWB is the right default.)
Drag the glass around. The fix here is simulated from the JPEG; the camera does it properly, for free.
MENU›Photo›Image Quality›Picture Quality›RAW+FINE
Why: a JPEG is the camera's final answer, with white balance and clipped highlights baked in. A RAW keeps what the sensor saw, so wrong white balance becomes a slider instead of a ruined photo. JPEG goes to Google Photos, RAW stays on the Mac as the negative.
It costs space: about 74 MB a shot, so roughly 200 shots on your 16 GB card. The counter on the screen is the real number.
MENU›Photo›Image Quality›Aspect Ratio›3:2
Why: the sensor is 3:2. 16:9 chops the top and bottom off and throws away 16% of your pixels, which happened on 803 of your 1,093 frames. You can always crop to widescreen later. You can't uncrop.
MENU›Setup›Others›Clock Set then Setup›Others›Time Zone
Why: your files are stamped UTC+1. A wrong zone puts photos on the wrong day, so your ~/Pictures/YYYY-MM-DD folders and your Google Photos timeline sort wrong. Change the zone when you travel.
Why: you're on 3.0. Version 3.1 and later read the color tag on your looks (without it the camera treats them as V-Log), add look strength (opacity), 39 look slots and the LUMIX Lab app. Later versions add more subject detection and a shutter speed limiter. Do this before loading looks.
.bin file to the top level of the card. Only one firmware file at a time.1,093 JPEGs from April 2025 to October 2026, all on the 50mm. The pencil marks are the patterns worth breaking.
P1001124 · f/9 · 1/30 · ISO 6400
f/9 buys depth you don't need on a flat facade and costs over three stops of light. The camera paid for it with ISO 6400, which is the grain. At f/2.8 the same shot is ISO 640. At f/1.8, ISO 250. That's what C2 is for.
P1003760 · f/6.3 · 1/15 · ISO 6400
1/15 can't freeze a dog. The aperture was the cause: at f/1.8 the same light gives about 1/180. With a Min. Shutter Speed floor (see Exposure) the camera wouldn't have dropped that low in the first place.
P1003131 · f/1.8 · 1/5000 · ISO 100
The opposite mistake. f/1.8 in full sun gave 1/5000 and a thin slice of focus. f/8 makes the whole city sharp and still gives 1/250. Wide open is for dim light and soft backgrounds.
P1002736 · f/16 · 1/100 · ISO 100
Small apertures turn the sun into a star, and f/16 is the place to stop. This lens is sharpest from f/2.8 to f/11; past f/16 diffraction softens everything. 91 of your frames were at f/22.
P1002914 · f/4 · 1/2000 · ISO 100
Fast shutter froze the spray into a sheet of glass, f/4 kept the rider sharp, ISO stayed at base. Good light, right settings. Every section below is about getting this result on purpose.
The mode dial is this camera's profile system. Set the camera up, save it to a C slot, and it comes back every time you turn to it. Tap a position.
You choose the aperture, which is the look. The camera chooses shutter and ISO. With a Min. Shutter Speed floor it raises ISO before the shutter gets slow enough to blur.
A C slot is a snapshot. Change something while you're on C1 and it snaps back the next time you turn the dial. Change A and it stays.
Physical controls aren't saved. The drive dial (top left, for burst) and the focus lever (back) stay wherever you leave them, so flip them yourself.
Positions are shown in the order the manual lists them; your dial's engraving is the reference.
On A you only pick one of the three. Pick the aperture for what should be sharp, and set two limits once so the camera can't make the expensive choices for you.
The S 50mm f/1.8 is sharpest from f/2.8 through f/11, per Photography Blog's test. Past f/16, diffraction softens everything.
MENU›Photo›Image Quality›Min. Shutter Speed›1/125
With Auto ISO, the camera keeps the shutter at 1/125 or faster and raises ISO instead. A little grain beats a blurry photo every time. Works in P and A. Your 188 frames slower than 1/60 would have traded blur for grain.
Press +/− on the top plate and turn a dial. ±5 stops for photos, ±3 for video. If a bright sky is washing out, try −1.
Make it visible: Custom›Monitor / Display (Photo)›Histogram and Blinking Highlights in the same menu. Blinking areas on playback are blown out.
Focus is three physical controls and one choice. Get these right and the S5II tracks faces and dogs on its own.
| Subject | Lever | AF mode |
|---|---|---|
| Dog, kids, surf | C | Tracking + Animal or Human |
| People posing | C | Full Area + Human |
| Buildings, landscapes | S | 1-Area |
| Through glass or a fence | S | Pinpoint, or MF |
A look is a LUT: a color recipe the camera bakes into the JPEG. The RAW stays neutral, so a look you hate later costs you nothing.
Previews are rendered on a Mac from a corrected JPEG, so they're close, not exact.
.cube files are already on the top level of your card.Each file is tagged #LUMIXPHOTOSTYLE NAT under its title line. Firmware 3.1 and later read that tag and start from Natural. An untagged file gets treated as V-Log, which is why loading looks before the update is a waste.
Regenerate or tweak them on the Mac with ./lumix.py luts and push to the card with ./lumix.py push.
Turn the dial to the movie camera (Creative Video) and use M. All four run fine on a V30 card. Most of what makes footage look good is the shutter rule below.
| Shooting | Dial | Setting |
|---|---|---|
| Everyday | Creative Video, M | MOV 4K 29.97p, 4:2:0 10-bit, 150 Mbps |
| Smooth motion, 2× slow-mo | Creative Video, M | MOV 4K 59.94p, 4:2:0 10-bit, 200 Mbps (APS-C crop) |
| Real slow motion | S&Q | FHD 120 or 180 fps |
| Heavy color grading | Creative Video, M | MOV 4K 29.97p, 4:2:2 10-bit, V-Log |
1/60 at 30p, 1/125 at 60p. That's the motion blur your eye reads as "film." In daylight at f/1.8 it overexposes, and there's no built-in ND, so carry a 67 mm variable ND filter for this lens.
Stabilization: body I.S. is always working. Add E-Stabilization (Video) when walking, Boost I.S. (Video) for still handheld shots.
Color: Standard or Natural if you won't grade. V-Log only if you will; it looks flat until you do.
Space: 150 Mbps is about 14 minutes on your 16 GB card and nearly two hours on a 128 GB one.
Your card is empty now: all 1,275 files were matched byte for byte against ~/Pictures before anything was deleted. It wasn't formatted. Next time, this is the routine.
~/Pictures/YYYY/YYYY-MM-DD, RAW (.RW2) next to its JPEG.Once the dial is set up: Setup›Card/File›Save/Restore Camera Setting›Save, name it DAILY. Then run ./lumix.py backup to copy it to the Mac.
That file is the only way to load a whole setup back into the camera. Names are up to 8 capitals and numbers, ten files per card, S5II only.
A 128 GB V30 SDXC. That's all this body needs, even for 4K 60p. The second slot can hold a backup copy of every shot: Setup›Card/File›Double Card Slot Function.
Everything above on one page. Print it, fold it, keep it in the bag.
If it isn't there, add it: Custom›Operation›Q.MENU Settings›Item Customize (Photo). A second way in besides the button.
Custom›Monitor / Display (Photo)›Level Gauge. It goes green when the horizon is straight.
Same menu, Auto Review, about 1 second. A glance, then back to shooting.
Constant Preview, same menu, makes the screen show the real brightness of your M settings. Turn it off to focus in the dark.
Edit Title takes up to 22 characters, and the name appears when you turn the dial. No more guessing what C2 was.
A DMW-BLK22 is good for a few hundred shots. Cold drains it faster, so keep the spare in an inner pocket.
After firmware 3.1+, the LUMIX Lab app sends looks to the camera from your phone. It can't run alongside LUMIX Sync.
A USB-C power-delivery bank can run the camera during long video takes or time-lapses.
